Q235 Carbon Steel Pipe refers to a type of steel pipe made from Q235 grade carbon steel, which is governed by the Chinese standard GB/T 700. This grade of steel is commonly used in construction and manufacturing due to its moderate strength and good formability.
Ingredients:
Carbon Steel: The primary material in Q235 Carbon Steel Pipe contains approximately 0.14-0.22% carbon content, along with small amounts of manganese, silicon, sulfur, and phosphorus. The composition allows for a balance between strength and ductility.
- Carbon: Increases hardness and strength but can reduce ductility when present in higher quantities.
- Manganese: Enhances tensile strength and hardness while improving wear resistance.
- Silicon: Improves strength and also acts as a deoxidizer during steel production.
- Sulfur and Phosphorus: Are considered impurities that can negatively affect toughness and weldability; their content is limited in Q235 to maintain acceptable mechanical properties.
Uses:
- Structural Applications: Q235 pipes are widely used in structural projects such as bridges, buildings, and other heavy-duty structures where medium load-bearing capacity is required.
- Piping Systems: They're suitable for water supply lines, drainage systems, and low-pressure gas pipelines, particularly in non-critical applications.
- Mechanical Parts: Components for machinery and equipment that do not demand high-strength or high-temperature resistance can be fabricated using Q235 pipes.
- Welded Structures: Due to its adequate welding performance, Q235 steel pipes are often employed in welded frames and supports.
In summary, Q235 Carbon Steel Pipes offer a practical and economical solution for a variety of applications where a balance between strength, formability, and cost-effectiveness is crucial. They are prevalent in the construction industry, general fabrication, and piping systems with lower stress requirements.
Product Name
|
Q235 Carbon Steel Pipe
|
Standard
|
ASTM,AISI,DIN,EN,BS,GB,JIS
|
Grade
|
ASTM/ASME: A36, A283, A285, A514, A516, A572, A1011/A1011M
|
GB: Q195, Q235/Q235B, Q255, Q275, Q345/Q345B, Q420, Q550, Q690
|
JIS: SS400, G3131 SPHC, G3141 SPCC, G4051 S45C, G4051 S50C
|
AISI: 1018, 1020, 1045
|
Technique
|
Hot rolled / Cold rolled
|
Type
|
Mild steel / Medium carbon steel / High carbon steel
|
Surface
|
Coated
|
Processing
|
Welding, Cutting, Bending, Decoiling
|
Delivery time
|
10-30 days subject to the clients' requirement and quantity
|
Package
|
clients' requirement and Standard export sea-worthy packing
|
MOQ
|
1 ton
|
Chemical Composition
Chemical Composition (heat analysis), %, ≤
|
Steel Grade
|
Quality Grade
|
C
|
Si
|
Mn
|
P
|
S
|
Q235
|
Q235A
|
0.22
|
0.35
|
1.40
|
0.045
|
0.050
|
Q235B
|
0.20
|
0.35
|
1.40
|
0.045
|
0.045
|
Q235C
|
0.17
|
0.35
|
1.40
|
0.040
|
0.040
|
Q235D
|
0.17
|
0.35
|
1.40
|
0.035
|
0.035
|
Physical Properties
Physical Properties
|
Density, g/cm3 (lb/in3)
|
7.85 (0.284)
|
Melting point, °C (°F)
|
1450-1530 (2640-2800)
|
Specific heat capacity, J/(Kg·K)
|
470 at 20 °C (68 °F)
|
Electrical resistivity, μΩ·m
|
about 0.15 (20 °C)
|
Elastic modulus, GPa (ksi)
|
200 (29 x 103)
|
Thermal conductivity, (W/m·K)
|
53-49 (0-100 °C)
|
Coefficient of thermal expansion, (10-6/K)
|
11.3-11.6 at 20-100 °C (68-212 °F)
|
Young's modulus, GPa (ksi)
|
200 (29 x 103)
|
Poisson's ratio
|
0.24-0.28
|
